제품 상세 정보:
|
| 작업 온도: | -20C~180C | 체르티파이온: | ISO, DIN |
|---|---|---|---|
| 제품: | 맞춤형 OEM 워터 펌프 씰 | 균형: | 불안정한 |
| 표준 또는 논스탠드: | 기준 | 수출 지역: | 전 세계 |
| Flygt 펌프 씰: | Gorman 펌프 씰 | 유동적 호환성: | 물, 기름, 가벼운 화학물질 |
| 장착형: | 직접 교체 | 자리: | 세라믹, SiC, TC |
| Parameter | Specification |
|---|---|
| Model Number | Gorman Rupp |
| Type | Cartridge Seal / Balanced Design |
| Material Options | |
| - Primary Sealing Face | Silicon Carbide (SiC) / Tungsten Carbide (WC) |
| - Secondary Seals | Ethylene Propylene (EPDM), Hydrogenated Nitrile (HNBR) |
| - Metal Components | Stainless Steel (SS316), Hardened Steel |
| Operating Limits | |
| - Pressure Range | 0-1.5 MPa (217 psi) |
| - Temperature Range | -30°C to +200°C (-22°F to +392°F) |
| - Max. Speed | 25 m/s (≈82 ft/s) |
| Shaft Diameter | 15-150 mm (0.6-6 in) [Adjustable] |
| Fluid Compatibility | Water, Sewage, Oils, Slurries, Mild Chemicals |
| Standards | ISO 9001, ANSI/API 682 (Type A/B Optional) |
| Applications | Wastewater Pumps, Industrial Pumps, Agitators |
Description:
Pressure: 1.2 MPa or less
Temperature: - 30 ~ 210 ºC
Linear Speed: 18 m/s or less
Structure: Single End
Pressure: High Pressure Mechanical Seals
Speed: General Speed Mechanical Seal
Temperature: High Temperature Mechanical Seal
Performance: High Pressure
Standard: Specifically Designed
Model NO.: Gorman Rupp Model T3/T4/T6 Model T8 Model T10
Balance: Balanced
Specification: Inner Diameter: 1.25 inch , 1.5 inch , 1.875 inch , 2.25 inch , 2.75 inch
Material:
Rotary Ring Face: SiC/TC
Stationary Ring Face: SiC/TC
Elastomers: Viton/EPDM/FFKM
Springs: SS304/SS316
Metal Parts: SS304/SS316
We have large stock, so our delivery is very fast.
For example,if products are standarded, the delivery time is one week.
Our company and factory addrss: Guangzhou City, GuangDongProvince,China.
Our city has a large port and an airport, so its transportation is very convenient.
담당자: ZENG
전화 번호: +8617620005542
